Home > Calorex UK > Calorex DH 150 Floor Standing Refrigerant Dehumidifier - 230v/400v

Calorex DH 150 Floor Standing Refrigerant Dehumidifier - 230v/400v 150 Litres

  • Calorex DH 150 Floor Standing Refrigerant Dehumidifier - 230v/400v
  • Calorex DH 150 Floor Standing Refrigerant Dehumidifier - 230v/400v
  • Calorex DH 150 Floor Standing Refrigerant Dehumidifier - 230v/400v
  • Calorex DH 150 Floor Standing Refrigerant Dehumidifier - 230v/400v
  • Calorex DH 150 Floor Standing Refrigerant Dehumidifier - 230v/400v
  • Calorex DH 150 Floor Standing Refrigerant Dehumidifier - 230v/400v
  • Calorex DH 150 Floor Standing Refrigerant Dehumidifier - 230v/400v
  • Calorex DH 150 Floor Standing Refrigerant Dehumidifier - 230v/400v
Save
10%
  • Removes Up To 150L/Day
  • Max Airflow of 2,500m3/h
  • Auto Constant Fan Flow
  • Hot Gas Defrost
  • Integral Humidistat
  • Low Noise Operation
  • Hose Connection For Continuous Drainage
  • Operating Temp Range of 0-35°C
Price Match
Rapid Delivery
In-Stock
1 Year Warranty
£6,100.00
£6,588.00 (inc VAT)
£5,490.00

Call FREE for expert advice

0808 196 9380

Features

Removes Up to 150L/Day: This industrial dehumidifier is an exceptionally easy drying solution to install, operate and manage in demanding areas with a max airflow rate of 2,500m3/h.

230v & 3 Phase (400v) Model Available: Choose from either the DH 150AX (230v) or the DH 150BX (3 Phase).

Steel Casing: These dehumidifiers are built to a high standard, with high quality components and a long-lasting plastisol coated galvanised steel cabinet, which has been designed to withstand tough environments.

Integral Humidistat: Featuring user-friendly controls, the in-built humidistat allows you to set the desired humidity level. When the relative humidity in the space varies from the set level, the machine will automatically turn on or shut down.

Hot Gas Defrost: Although refrigerant dehumidifiers are susceptible to ice formation at lower temperatures, this robust dehumidifier has a hot gas defrost system to melt the ice and allow the water to filter out with the condensation.

Low Noise: With an operating volume of just 58dB, which is the same volume as a normal conversation, this is an extremely quiet dehumidifier that is suited to areas that require minimum distribution.

Optional Accessories Available: A range of optional accessories are available for the Calorex DH 150 dehumidifier, including an air filter kit, a condensate pump, external condenser unit, compressor soft start, turning hoods, low pressure hot water option and an air inlet duct kit.

Please Note: This high capacity dehumidifier is made to order in the UK - there is a lead time of 6-8 weeks.

Product Video

Description

Calorex DH 150 Floor Standing Refrigerant Dehumidifier

Robust industrial 150L dehumidifier

The Calorex DH 150 Floor Standing Refrigerant Dehumidifier has been designed specifically for removing large volumes of moisture from spaces such as warehouses, metal storage, electrical sub-stations, museums, art galleries, furniture storage and classic car storage facilities. With the ability to remove up to 150 litres of water per day, this high-moisture extraction floor standing dehumidifier is also suitable for data centres, offices, archives, sports halls, gyms and more.

Control humidity levels with integral humidistat

The Calorex DH 150 is a self-contained industrial dehumidifier with integral humidistat that allows you to set the desired humidity level. When the relative humidity in the space varies from the set level, the dehumidifier will automatically turn on or shut down.

Quality components built to last

Made from plastisol coated galvanised steel, the DH 150 is a tough, high-performance dehumidifier that recirculates the air and physically removes moisture thanks to a maximum air flow 1,180m3/h. It has a constant fan flow that automatically adjusts to ducting and is equipped with a polyester coated evaporator and condenser. This Calorex dehumidifier has a heat output of 9kW at 80°C and boasts heat recovered to air at 30°C/60% RH is 7.4kW.

Removes moisture to protect sensitive spaces

Effective dehumidification provides maximum protection in spaces such as museums and historic buildings, where priceless exhibits and artefacts are stored. If the relative humidity is too high, condensation can form on surfaces and mould and rot can set in while the rising and falling of humidity levels can cause degradation.

This can be avoided by maintaining the relative humidity at correct and stable levels. The Calorex DH 150 high capacity dehumidifier's functionality and easy operation make it ideal for period properties, museums and archives or anywhere where preservation is vital.

Helps maintain safe humidity levels

These dehumidifiers also help prevent corrosion of vulnerable metal surfaces, body panels and dry damp rooms substantially quicker than heat to the point where classic cars can be stored for periods of time without moisture related degradation.

Storage of such equipment as steel at the correct humidity is critical and can often reduce the requirement for additional surface protection systems while in storage.

Where data centres are constructed in climatic regions that experience high air temperatures and moisture contents, humidity control, humidity control is essential to stop moisture in the fresh air supply from condensing into the room, risking damage to valuable data centre infrastructure and operation.

Hot gas defrost function helps perform in low temperatures

Although refrigerant dehumidifiers are susceptible to ice formation at lower temperatures, the DH 150 is equipped with a hot gas defrost system to melt any ice and has an operating temperature range of 5-35°C. With an operating volume of just 58dB, which is the same volume as a normal conversation, this is an extremely quiet dehumidifier that is suited to areas that require minimum disruption.

Optional Accessories Available

A range of optional accessories are available for the Calorex DH 150 dehumidifier, including an air filter kit, a condensate pump, external condenser unit and compressor soft start.

Turning hoods are available for the DH150, which sit on top of the unit and allow the direction of the airflow to be altered. We have both a standard turning hood and a turning hood with a 9kW electric heater available for this model.

We also have a low pressure hot water (LPHW) option. The LPHW option is a heating coil which can be added inside the unit. It works the same as a radiator in your house - so it needs to be plumbed into a boiler system. It provides a source of heat which warms the air, allowing it to absorb more moisture that the dehumidifier can extract, and it provides a heat source for occupants working within the space.

An air inlet duct kit is also available, which allows the dehumidifier to be used with a ducting system, to draw air in over large areas in spaces such as factories, warehouses and food production facilities.

Please Note: This high capacity dehumidifier is made to order in the UK - there is a lead time of 6-8 weeks.

Specification

DH 150AX (230v)
Operating temperature range: 0-35
Dehumidification @ 30°C/60% RH: 150L/24h
Heat recovered to air @ 30°C/60% RH: 7.4kW
Air flow: 2500m3/h
External static pressure: 0-200Pa
Sound pressure level @ 3m: 58dB(A)
Refrigerant: R407c
Power supply: 230/ph/50V/Hz
Nominal power consumption: 2.5kW
FLA: 21A
Maximum supply fuse: 30A
LRA (compressor start): 61A
LRA (compressor soft-start): 28A
Heater type: Top box electric
Heat output: 9kW
FLA (heater): 36A
Maximum fuse size: 50A
Product size (w x d x h): 660 x 660 x 1313
Weight: 130/130kg
Condensate drain size (flexible plastic hose): ¾ BSPM

DH 150BX (3 Phase)
Operating temperature range: 0-35°C
Dehumidification @ 30°C/60% RH: 150L/24h
Heat recovered to air @ 30°C/60% RH: 7.4kW
Air flow: 2500m3/h
External static pressure: 0-200Pa
Sound pressure level @ 3m: 58dB(A)
Refrigerant: R407c
Power supply: 400/3ph/50V/Hz
Nominal power consumption: 2.5kW
FLA: 11A
Maximum supply fuse: 16A
LRA (compressor start): 30A
LRA (compressor soft-start): 13A
Heater type: Top box electric
Heat output: 9kW
FLA (heater): 12A
Maximum fuse size: 16A
Product size (w x d x h): 660 x 660 x 1313mm
Weight: 130kg
Condensate drain size (flexible plastic hose): ¾ BSPM inch
