Trotec 1008631 Qube+ Pressure Drying System 250 m³/h

TROTEC QUBE+ PRESSURE DRYING SYSTEM

4-IN-ONE VERSATILE & COMPACT DEVICE

The Qube+ is the only integral insulation drying solution on the market. This exclusive pressure dryer substitutes for four devices, replacing the need for multiple units—presenting a simple, space-saving alternative to multi-device solutions.

Featuring a powerful VX-5 turbine insulation dryer, a WA-4i water separator, a 4-stage HEPA filter system and efficient NR19 silencer and any side channel compressor with a performance class from 0.4kW to 3kW. These devices are installed and ready for use integrated in the ultra-compact and stackable aluminium construction.

Thanks to its ultra-compact design, the Qube+ consumes minimal space yet boasts an exceptionally large drying capacity. The convenient single all-in-one unit means there is less to lift, carry, assemble, and connect. Includes integrated night function for whisper-quiet operation; ideal for use in occupied environments.

ACHIEVE MORE WITH EASE

ADAPTIVE. EFFICIENT. AUTOMATIC.

Eco-friendly and energy-efficient operation is central to the design of the Qube+. The four-step variable turbo motor produces up to 20,000 rpm and guarantees maximum efficiency at any of the four power stages available.

Power stage one is designed for the economical drying of smaller surfaces. Exceptionally, each power stage ensures from 10% up to 160% more efficiency than separate side channel compressor units.

The Qube+ impresses with the HiDry automatic control system. Much like cruise control, the sensor supported HiDry automatically adjusts the volumetric flow rate to the pre-set optimum value of the chosen power stage. The HiDry ensures that the turbo motor does not generate more power than necessary, guaranteeing maximum energy-efficiency in each stage of every drying application.

TECHNICAL DATA
General information
Article Number: 1.560.000.055
Suitable for surfaces sized up to (low pressure)
Level 1 [m²]: 25
Level 2 [m²]: 50
Level 3 [m²]: 85
Peak low pressure
Max. low pressure [mbar]: 220
Air volume (freely blowing)
Max. air volume freely blowing [m³/h]: 250
Volumetric flow rate HiDry (sucking in)
Level whisper mode [m³/h]: 90
Level 1 [m³/h]: 90
Level 2 [m³/h]: 140
Level 3 [m³/h]: 160
Level Boost mode [m³/h]: 180
Motor power
Level min. [kW]: 0.2
Level Max. [kW]: 1.2
Sound values
Level min. - Distance 3 m [dB(A)]: 48
Level Max. - Distance 3 m [dB(A)]: 62
Collection container
Volume [l]: 10
Electrical values
Mains connection: 230 V/50 Hz
Nominal current consumption [A]: 6.7
Recommended fusing [A]: 16
Electric connection
Connection plug: CEE 7/7
Cable length [m]: 3.5
Dimensions
Length (packaging excluded) [mm]: 490
Width (packaging excluded) [mm]: 500
Height (packaging excluded) [mm]: 735
Weight
(packaging excluded) [kg]: 25.2

Unique Insulation Drying Solution: This exclusive all-in-one system replaces the need for multiple units, so there is less to lift, carry, assemble and connect.

4-in-1 Solution: Featuring the powerful XV-5 turbine insulation dryer with an exceptionally large drying capacity, WA-4i water separator, 4-stage HEPA filter system, and NR19 silencer, for flexible drying of low-pressure surfaces ranging from 10m² to 85m².

Portable & Stackable: Fitted with an extendable handle, the Qube+ is designed to be wheeled to any damage site with ease and speed. The stackable design ensures safe storage and allows the connection of multiple Qube+ devices.

Compact Cube Construction: Up to 75% smaller than competitive designs, the Qube+ consumes minimal space yet boasts an exceptionally large drying capacity.

Four-step Variable Turbo Motor: Producing a maximum 20,00 rpm, each power stage consumes from 10% up to 160% less energy than separate side channel compressor units.

HiDry Automatic Control System: The sensor supported HiDry automatically adjusts the volumetric flow rate to match the chosen power stage – guaranteeing optimum energy-efficiency in each stage of every drying application.

Night Function: Includes integrated whisper-quiet operation mode, ideal for use in occupied environments.

DA 4 Interface: For real-time remote monitoring of the system status and drying progress.
