Arcotherm Jumbo 235M Indirect Space Heater

Exceptional heating and drying capabilities

The Arcotherm Jumbo 235M is a fast, efficient, and effective indirect space heater capable of providing warm, clean air for large, open areas. You can improve the working conditions of factories, warehouses, garages, and more during colder periods. The 235M is also adept at heating public event spaces like marquees, unattended rooms such as stables and farmhouses, and for drying applications. The Jumbo 235m is ideal for large scale drying on construction sites, in buildings following heavy downpours or flooding, or for agricultural applications like crop drying, and more. Indirect space heaters are safe to use for any space as they supply a clean air output while the fumes are exhausted separately. This powerful space heater provides 218kW of output with 92% heating efficiency and a massive 17000m³/hr airflow.

Robust, Durable & Resilient

Exceptional build quality

Featuring Arcotherms new, redesigned combustion chamber and higher performance 7-bade fans, the Jumbo 235M is incredibly efficient and quiet and can cope with the demands of all challenging environments. The robust design and construction are perfect for industrial applications, and the low noise level makes it suitable for commercial and domestic use too. Other large, powerful space heaters of this size can be loud and disruptive to productivity. Every significant component, such as the fan, burner, thermostat, etc., are provided with quick couplings for faster assembly, maintenance, and eliminate mistakes. These quick couplings have an IP65 rating to protect against ingress of small particles like dust and water and are also secured underneath the sturdy burner cover. The burner cover has reinforced panels for impact resistance and combines with the weight bearing structure to provide anchorage and structural strength. The electrical control panel is placed at the top rear of the heater to avoid contact with the ground, snow, water, and dust allow.

Powerful Indirect Space Heater

Reliable, adaptable & versatile

The Jumbo 235M is an effective and convenient space heater. There is also an excellent range of additional extras available to customise the unit for your specific needs. Robust PVC ducting can be purchased to direct clean, warm air to one area or separate spaces using splitters. The 2 and 4-way outlet splitters can be used in conjunction with muliple lengths of PVC ducting so that you can heat more than one space at the same time. You can heat anywhere up to 5 metres away from the heater, which is ideal for areas with limited floor space or have lots of foot traffic. The standard ducting, splitters, splitter ducting, thermostat, flue, and rain cowl are available to select with the tick boxes below your cart. We can also supply a fuel tank, side bumper kit, lifting kit, swivelling wheels kit, pre heated oil filter, flue storage kit, and chimney support kit available on request. All the accessories allow you to safely leave the Jumbo 235M running unattended for long periods with the fumes extracted outside of the space. Enquire today or order with confidence via our online checkout or by phone to talk to our expert sales team directly.

Heater Dimensions: 2245mm x 982mm x 1584mm
Packaged Heater Dimensions: 2200mm x 880mm x 1560mm
Product Weight: 357kg
Packaged Weight: 377kg
Heating Capacity: 218kW
Heat Efficiency: 92%
Air Flow: 17,000m³/h
Air Temperature: 55℃
Fuel Consumption: 18.65l/hr
Electrical Power: 2550W

100% Clean Hot Air: The heater blows out 100% clean, fume-free warm air from its warm air outlet. This makes it ideal for heating enclosed areas safely, such as marquees and tents, workshops, warehouses, areas on construction sites and much more.

Ducting Connection: Sections of ducting can be attached to this heater, in order to direct the clean warm air into the space that you need to heat.

Flue Gas Exhaust: Combustion by-products are exhausted out of the top of the heater. Sections of flue pipe are available separately, allowing you to safely vent exhaust fumes away from the space.

High Quality Components: High-performance 7-blade fan assembly and redesigned combustion chamber.

Tough & Robust: Built to perform in challenging areas, including construction sites, workshops, warehouses, agriculture, events and more.

Portable Design: Large wheels and a handle make the heater very portable. It is easy to transport, position and re-position when required on site. Lifting eyes on top of the unit allow it to be lifted on and off transport.

Thermostat Connectivity: An optional heavy duty thermostat can be connected to this heater, allowing you to set a required temperature within the space. The thermostat will switch the heater on and off as required in order to maintain the set temperature. This saves fuel and adds extra convenience.

Tigerloop Available: This heater features no internal fuel tank. It is designed to be connected to an external fuel tank of your choice. The tigerloop removes any air from the fuel as it enters the heater.
