Arcotherm EC22 Indirect Oil Fired Space Heater - 240v/110v 19kW

Arcotherm EC22 Indirect Space Heater

Compact & Portable 19kW Heater

The Arcotherm EC22 is a 19kw indirect diesel space heater with an automatic built in oil burner and a Danfoss pump, ensuring reliable, premium performance.

Featuring a robust hydrocarbon resistant polythene fuel tank, AISI 430 stainless steel combustion chamber, electronic flame control, safety thermostat and electronic control panel, this indirect space heater is made from the highest quality, most reliable components to ensure maximum safety and efficiency.

Premium Performance Diesel Heater

Ideal Solution For Heating Temporary Structures

This tough and reliable indirect oil fired diesel heater that is to be placed outside the target space with clean and fume-free heat ducted into the space. Meanwhile, any fumes are exhausted outside.

The Arcotherm EC range of indirect diesel heaters are an ideal heating solution for events and marquee hire industries, as they provide a reliable and effective source of clean heat for enclosed areas such as marquees, halls and more.

The EC22 is attached to a sturdy wheel-mount fixed with a handlebar, which enables easy transportation and positioning. The EC22 can also be used in conjunction with 2m of ducting, to deliver heating to specific areas further away from the heater.

Available as part of a heating package!

We also have the EC22 indirect diesel heater available as part of our small marquee heating package – supplying you with everything required to heat a marquee or similar construction, at a great price, with FREE DELIVERY!

Please Note: These units are not suitable for use with waste oil.

Heat Output (kW): 20
Voltage (V): 110/240
Airflow m³/hr: 550
Fuel Consumption (Litres/hr): 1.9
Dimensions: 615mm x 440mm x 1075mm
Weight (Kg): 40
Hose Length (Metres): 2
Hose Diameter (mm): 250
Tank Capacity (Litres): 42
Thermal Efficiency (%): 84

100% Clean Hot Air: The heater blows out 100% clean, fume-free hot air. Sections of flue pipe are available separately, allowing you to safely vent exhaust fumes away from the space.

Ducting Connection: 2m length of ducting can be attached to this heater, in order to direct the clean warm air into the space that you need to heat.

Ideal For Temporary Structures: This tough and robust heater is built to perform in challenging areas, offering an ideal solution for temporary structures including marquee tents, workshops, construction sites and more.

High Quality Features: Robust hydrocarbon resistant polythene fuel tank, AISI 430 stainless steel combustion chamber, automatic built-in oil burner, Danfoss pump, electronic flame control, electronic control panel, and an overheat thermostat to ensure maximum safety and reliable performance.

Portable Design: The EC22 is attached to a sturdy wheel-mount fixed with a handlebar, which enables easy transportation and positioning.

Thermostat Connectivity: An optional thermostat can be connected to this heater, allowing you to set a specific room temperature. The thermostat will operate in accordance to maintain your settings – saving fuel, energy, costs and adding convenience.
