Olimpia Splendid Unico Air 8 HP Air Conditioner with Heat Pump 230v 1.8kW

Olimpia Splendid Unico Air 8 HP Wall Mounted Air Conditioner

Super Slim & Quiet Air Conditioner with Heat Pump

The Unico Air 8HP Wall Mounted Air Conditioner is one of the thinnest and quietest air conditioners in its range thanks to Inverter Technology. Measuring only 16cm in depth, it is super compact compared to most other units of the same power that usually require an external condenser.

The Unico Air 8HP is a pure system, equipped with a multi-filtering system, consisting of an electrostatic filter (with anti-dust function) and activated carbon filter (effective against unpleasant odours) to help improve air quality. anks to sound-absorbing and anti-vibration materials, it also ensures low noise levels, so it does not disturb you while it works.

This modern through-the-wall air conditioner requires no external condenser unit, so it can be installed quickly and easily. The impact on the outside wall is minimal with only two small 162mm diameter grilles visible. All installation work can be undertaken from inside the building, including the drilling of the holes and fitting of the two grilles. With just one unit to install and no interconnecting pipework needed, installation is made easy.

The Unico Air 8HP boasts a heat pump, which means that you can replace or support traditional heating during colder weather. anks to this feature you you can replace or support traditional heating in intermediate seasons. Unico Air also offers a dehumidification mode, absorbing excess moisture.

Cooling power (min/max) kW: -
Heating power (min/max) kW: -
Nominal cooling capacity (1) kW: 1.8
Nominal heating capacity (1) kW: 1.7
Nominal power consumption for cooling (1) kW: 0.7
Nominal absorption for cooling (1) A: 3.1
Nominal power consumption for heating (1) kW: 0.5
Nominal absorption for heating (1) A: 2.5
Nominal energy efficiency index (1): 2.6
Nominal efficiency coefficient (1): 3.1
Energy efficiency class in cooling (1): A
Energy efficiency class in heating (1): A
Energy consumption in “thermostat off” mode W: 14
Energy consumption in “standby” mode (EN 62301) W: 0.5
Energy consumption for double pipe appliances (1) cooling function kWh/h: 0.7
Energy consumption for double pipe appliances (1) heating function kWh/h: 0.5
Supply voltage V-F-Hz: 230-1-50
Supply voltage (min/max) V: 198 / 264
Maximum power consumption in cooling mode kW: -
Maximum absorption in cooling mode A: -
Maximum power consumption in heating mode kW: -
Maximum absorption in heating mode A: -
Dehumidification capacity l/h: 0.6
Air flow rate in cooling environment (max/med/min) m³/h: 215/180/150
Air flow rate in heating environment (max/med/min) m³/h: 215/180/150
External air flow rate in cooling (max/min) m³/h: 380
External air flow rate in heating (max/min) m³/h: 380
Internal ventilation speed: 3
External ventilation speed: 1
Diameter wall holes** mm: 162
Electric resistance heating: -
Maximun remote control range ( distance / angle ) m / °: 8 / ±80°
Dimensions (WxHxD) (without packaging) mm: 978 x 491 x 164
Dimensions (WxHxD) (with packaging) mm: 1060 x 595 x 250
Weight (without packaging) kg: 37
Weight (with packaging) kg: 41
Internal sound pressure (min/max) (2) dB(A): 27-38
Internal sound power level (EN 12102) LWA dB(A): 53
Degree of protection provided by covers: IP 20
Refrigerant gas* Type: R410A
Global warming potential GWP: 2088
Refrigerant gas charge kg: 0.47
Maximum operating pressure MPa: 4.2
Power cable (N° pole x section mm²): 3 x 1.5

(1) Test conditions: the data refer to the EN14511 standard - HEATING MODE: Temperature: outdoor environment DB 7°C / WB 6°C; indoor environment DB 20°C / WB 15°C -
COOLING MODE: outdoor ambient temperature DB 35°C / WB 24°C; indoor environment DB 27°C / WB 19°C
(2): Declaration of test data in a semi-anechoic chamber at a distance of 2m, minimum pressure in ventilation only.
* Hermetically sealed equipment containing fluorinated gas with GWP equivalent 2088.

Heat Pump: The Unico Air 8HP boasts a heat pump, which means that you can replace or support traditional heating in intermediate seasons.

Dehumidification: It includes a dehumidification mode for you to enjoy comfort without the "sticky" feeling caused by humidity.

Slim Design: Measuring only 16cm in depth, the Unico Air 8HP is super compact.

Silent System: Unico Air boasts one of the lowest noise levels in its range with operation volume dropping as low as 27 dB(A).

Regenerated Gas: The Unico Air uses reclaimed R410A. This is a refrigerant identical to the original one, but recovered from existing systems.

Inverter System: Constantly adjusts the motor speed according to the set temperature and helps optimise energy consumption.

Wall-mountable: The Unico can be installed on the wall using internal fixing points.

Easy-To-Use Controls: Multi-function remote control with a 24h timer.
