Sonniger GUARD Ambient Air Curtain 2,000(m3/h) - 4,800(m3/h)

Sonnier Guard Ambient Air Curtain

High Perfomance Temperature Regulator

Struggling to maintain a comfortable indoor climate due to large entryways with high traffic? Heavy footfall entering a building will inevitably carry in outdoor air, massively impacting the temperature, causing discomfort and substantial increases in heating bills.

The Sonniger GUARD range of ambient air curtains efficiently minimise heat loss in high traffic entryways. These efficient air barriers are favoured by the commercial industry, with typical installation including shops, hotels, offices, reception areas and sport centres.

Each model features a sleek modern design to compliment and blend with any interior style. Mounting brackets are included for horizontal over door installation, though vertical mounting is possible with additional brackets sold separately. For larger openings, multiple units may be used in tandem for wider coverage.

The ambient range forms an invisible ambient air barrier preventing heat from escaping or entering the building. These models are perfect for year-round use. In winter periods, the barrier prevents the ingress of cold air inside the heated space, preventing energy loss. During summer, the fans may create a cooling effect as well as preventing heat from entering from outside.

Sleek, Cost-Effective & Efficient

The new and improved Sonniger GUARD range of air curtains boast high performance parameters with ambient air models delivering an impressive 2000-4,800m3/hr airflow, up to 4m mounting height and air throw.

The units facilitate flexible control options and three speed settings, altering the height of performance parameters, so you can specifically regulate the volume of heat loss from the entryway.

Noise levels are as low as 59 dB(A), meaning the invisible barrier will silently work away to preserve the indoor climate without a worry of disruption whilst the unit operates. All models in the range feature an operation temperature range of -10^oC to +40^oC, so the air curtain is suitable for use in challenging climates, such as industrial warehouses and factories. Plus, with an IP20 rating, the air curtains are protected from dust and debris kicked up by footfall passing through.

Model: Guard 100C Ambient-air

Unit Length (m): 1

Max Airflow (m3/hr): 2,000

Fan Consump. (A) On 230V Single Phase Supply: 1.95 A

Fan Motor Power (kW): 0.22

Noise Level (dB(A)): 59

Max Install Height (m): 4

Protection Class (IP): IP20

Model: Guard 150C Ambient-air

Unit Length (m): 1.5

Max Airflow (m3/hr): 3,600

Fan Consump. (A) On 230V Single Phase Supply: 2.6 A

Fan Motor Power (kW): 0.32

Noise Level (dB(A)): 61

Max Install Height (m): 4

Protection Class (IP): IP20

Model: Guard 200C Ambient-air

Unit Length (m): 2

Max Airflow (m3/hr): 4,800

Fan Consump. (A) On 230V Single Phase Supply: 2.6 A

Fan Motor Power (kW): 0.32

Noise Level (dB(A)): 62

Max Install Height (m): 4

Protection Class (IP): IP20

Temperature Efficient: The invisible barrier of air prevents ambient temperature loss, trapping heat indoors in winter periods. Alternatively, the unit may be used as a cooling device in summer, by preventing heat from entering the building.

Mounting Heights: Suitable for heights of 4 metres with mounting brackets included for horizontal above door installation.

Three Fan Speed Settings: Select between three fan speeds to alter the height of performance parameters, so you can regulate the volume of heat permeating into or exiting the building.

Modern Design: The sleek steel style will compliment and blend in seamlessly with any contemporary interior, an ideal addition to commercial spaces such as hotels and reception areas.

IP20 Rating: The Sonniger GUARD range is protected against solid objects and liquids, such as dust and debris carried in by wind or kicked up by footfall passing through.

-10^oC to +40^oC Operating Range: The GUARD air curtains are suitable for use in challenging climates, such as industrial warehouses and factories where temperatures can reach as low as -10^oC.
