Reznor UDSA050 Suspended Gas Fired Unit Heater 49kW

Reznor UDSA050 Suspended Gas Unit Heater

49kW suspended gas heater

The Reznor UDSA050 suspended gas heater is an innovative and efficient industrial heater. It is capable of warming large spaces such as workshops, garages, factories, warehouses, halls, retail outlets, sports halls, and more. This Reznor UDSA gas heater can heat these spaces quickly and for long periods to create more comfortable conditions for all occupants. It is designed to provide an economical climate solution that delivers oustanding performance levels with energy efficiency. The unit is robust and compact and features a titanium stabilised aluminised steel heat exchanger that enhances the service life expectancy of the heater. The advanced burner technology uses a self-aligning modulating burner that has a multi-try ignition to maximise its reliability. The Reznor USDA050 heater will always start when it is needed most - even in tough industrial environments and very cold conditions. All of the integral parts are of the highest quality and allow for easy maintenance. The unit also features a durable room seal to prevent the ingress of dirt, dust, water, and other particles that could damage the combustion system or affect its performance. The Reznor USDA050 is a powerful suspended gas heater that provides 49kW of heat with an airflow rate of 5180m3/h. The aerodynamic profile of the heat exchanger offers a minimal resistance to the airflow and combines with the integrated high capacity axial fan to provide a greater air throw to offer an even heat distribution throughout an entire space. The improved airflow reduces preheat times and reduces the temperature gradient that can occur from the floor to the ceiling in large spaces. The fan is made of durable aluminium, it is corrosion resistant and housed separately to the other components. The operation of the fan is controlled so that it delays start up until the heat exchanger reaches working temperature. It also keeps running until all of the useful heat has been circulated into the space. Additionally, the heat exchange achieves 92% thermal efficiency, making the Reznor USDA050 incredibly practical and cost effective. It is a versatile 230v suspended gas heater that requires a single-phase electrical supply. It is fired by natural gas (G20) as standard, but you can also order a model specified for use with Propane (G31).

Versatile Suspended Gas Heater

Multiple unit & flue installation

The Reznor UDSA050 suspended gas heater is designed for versatility and adaptability. It can be installed in any space that needs a robust and effective climate control solution. This gas-fired heater features four inbuilt suspension points that have an M10 female thread for quicker and easier installation. If the Reznor UDSA050 cannot be ceiling-hung for any reason, it can be mounted onto a suitable support instead. This must be a sturdy, non-combustible structure. The flue of the UDSA050 can be installed horizontally through a wall, vertically through a roof, or a combination of both. A range of 100mm flue terminals and flue appliances are available that allow you to set the heater up in whatever way is most suitable for the space. The standard flue terminals allow separate combustion air inlet and air outlet flues to be installed while the balanced flue terminal allows both to be installed through a single building penetration. The 100mm diameted flue sections include 250mm and 1m length sections, plus 90° bends, rain cowls, and cowl flashing plates. Multiple flue sections can be used up to a maximum distance of 9 metres. This distance is reduced by 1.5 metres for every 90° bend that is fitted. You can also purchase the SmartCom Multizone Control Panel, a Remote SmartCom Warm Air Sensor, 3/4" Flexible Gas Connector, and a 3/4" Gas Valve. We have all of the compatible parts available. The Reznor UDSA050 suspended gas heater and its flue system must be installed by a qualified heating engineer. We can recommend our trusted installers for your area if you need some guidance.

Innovative Reznor UDSA Gas Heater

Complete control at your fingertips

The Reznor UDSA050 suspended gas heater is a versatile unit with a robust, compact, aerodynamic design. It is safe to use in enclosed and densely populated commercial or industrial spaces, as the combustion air is exhausted outside of the space via the flue system. This practical heater also gives you maximum control of the climate, using Reznor SmartCom control panels. Reznor SmartCom control panels allow you to control the heater from a remote location. They are user-friendly units that feature all of the basic functions that you would expect, including adjustable temperature control and fan settings. There is also a self adapting optimum start and stop function that uses the integrated air temperature sensor. This turns the UDSA050 heater on or off automatically to maintain the correct climate. You can programme the panel for all of your specific requirements, so you do not have to alter the settings manually each day. There are daily on and off periods, seven-day programming, overtime, holidays, day, night, frost settings, and more. The programmes, functions and settings are all designed to deliver optimum efficiency and reduce running costs. There is an alphanumeric backlit display which allows for easy viewing and displays clock updates, temperature functions, settings, and service data logging for system overviews and maintenance. The Reznor SmartCom can communicate with up to 15 units which can all be centrally controlled by the one master control unit. Optional password protection can be set for added security. Passwords can help prevent any unauthorised access and system tampering. Order a Reznor UDSA050, flue pipe kits, and SmartCom control panels online or by calling us directly to talk to a member of our sales team. Our team has a wealth of experience and can help with any concerns or questions that you might have.

Nominal heat output kW: 49
Airflow m3/h: 5180
Temperature rise K: 28
Horizontal throw m: 32
Noise level @ 5m2 (Q=2, A=160m2) dB(A): 56
Gas Consumption
Natural gas G20 m3/h: 5.59
Propane G31 kg/h: 4.12
Gas connection Rc: 3/4"
Mounting height(s)
Horizontal m: 4
Vertical downflow m: 7.5 - 10
Total electrical Rating W: 500
Net weight kg: 102
Dimensions (W x H x L) mm: 970 x 510 x 1033
Flue & combustion air collars Ø mm: 100

100% Clean, Fume-Free Heat: Only clean, fume-free warm air is blown out of the heater, meaning it is suitable for heating enclosed, poorly ventilated space. It is ideal for garages, factories, warehouses, workshops, sports halls and more.

49kW Heating Capacity: Excellent heat capability for a compact and discreet heating unit.

Flue Connection: Combustion by-products are exhausted out of the flue exhaust. Sections of flue pipe are available separately, allowing you to safely vent exhaust fumes away from the space horizontally through a wall, vertically through a roof, or a combination of both.

Four Suspension Points: These inbuilt suspension points have M10 female thread for quicker and easier installation, allowing suspension from ceilings.

Titanium Stabilised Aluminised Steel Heat Exchanger: High quality component that offers efficient heating (92%) and enhances the service life expectancy of the heater. Its aerodynamic profile offers a minimal resistance to the airflow, to give longer air throw.

High Capacity Axial Fan: Designed for free blowing applications (without ducting). The fan provides excellent air throw, 5180 m3/h airflow and even heat distribution throughout the space. The fan is made of durable aluminium, it is corrosion resistant and housed separately to the other components.

Self-Aligning Modulating Burner: With multi-try ignition to maximise its reliability, ensuring the heater will always start when it is needed.

Differential Pressure Switch: Shuts down the unit in the event of inadequate combustion air, blocked flue or flue fan failure, ensuring safety and reliability.

Durable Room Seal: Prevents the ingress of dirt, dust, water, and other particles that could damage the combustion system or affect its performance.

Propane Option Available: This heater is designed to be fuelled by natural gas, however a model specified for use with propane can be ordered. The heater and its flue system must be installed by a qualified heating engineer.

Reznor SmartCom Control Panels Available: Allow you to control the heater from a remote location. They are user-friendly units that offer adjustable temperature control and fan settings, self adapting optimum start and stop function which turns the heater on or off automatically to maintain the correct climate. You can programme the panel for all of your specific requirements, so you do not have to alter the settings manually each day. The Reznor SmartCom can communicate with up to 15 units which can all be centrally controlled by the one master control unit.
