Heat4All SmartLine Infrared Panel Heaters 170w to 1kW

Heat4All SmartLine Infrared Panel Heaters

Innovative & effective heaters for the home

Heat4All SmartLine panels are infrared heaters that are low-cost, highly efficient and safe. They enable you to create a lovely room climate without taking up space, as they can be mounted onto a wall or ceiling. They look fantastic in any hallway, living room, bedroom, dressing room, hotel room or bathroom. They provide radiant heat on cold mornings, throughout chilly days, and harsh winter nights. Infrared is a natural and safe form of heating. Conventional heating systems raise the temperature of the air within a space, but Heat4All infrared panels offer a more direct form of heat. Infrared does not warm the air. It warms walls, furniture, objects and people. The heat stored within these surfaces is then re-emitted evenly to provide a comfortable and consistent level of heat. This process is completely natural - it is the same kind of heat that you would feel in the sun. Using an infrared panel heater, people in the room will start to feel warm just minutes after switching the unit on. This more subtle and consistent form of heating provides comfortable conditions for people in the room.

Affordable Heating

Low-cost, economical & energy efficient

With the SmartLine range, Heat4All have managed to create affordable infrared panel heaters that are also stylish, effective, and help improve your ecological footprint. SmartLine panels do not compromise on quality or performance. They have specially designed frames and mounting studs to ensure excellent stability and robustness. The front panel is coated steel with high IR radiation ratio and high UV persistence while the rear panel has a metallic surface and a lower IR-emissivity. Internally, Heat4All SmartLine panel heaters feature high-quality heating elements with constantan heating conductor and an air buffer insulation with an IR reflector. These components ensure heating efficiency, reduced energy consumption and reduced running costs.

Stylish & Discreet Infrared Heaters

Ideal for homes, offices, hotels & more

Heat4All SmartLine heating panels are slim, stylish and modern design features for homes, offices, hotel rooms, shops, showrooms and more. At just 16mm thick, these infrared panel heaters are extremely compact and discreet. They can be mounted onto a wall or ceiling, and the white powder coated finish fits beautifully into a range of architectural styles. These infrared panel heaters are available in a range of different sizes, each with different heating capacities, so they can be used for heating a range of spaces of different sizes. You can view the specifications for each model below, and you can select the model that you require using the drop-down menu above.

‘Plug & Play’ Panel Heaters

Easy to install yourself

One of the major plus points of Heat4All’s SmartLine infrared heaters is the ‘plug & play’ design. These panel heaters come with a 1.9m power cable and 230v plug, as well as an easy to use, sturdy, adjustable mounting kit and mounting manual. They do not need to be wired into the mains by a professional electrician. Simply mount the mirror on to a wall and plug it into a power socket. This makes these heaters very convenient to use and means that there are no extra costs for installation. It also means that the mirror can be moved elsewhere very easily if required.

Thermostat Options Available

Complete climate control

Heat4All SmartLine panel heaters can be used with an optional thermostat for full control of the heating within the room. Using a thermostat, you can set a desired ambient temperature or set a timer. The thermostat will switch the heater on when required and, once the desired temperature has been reached, it will switch the heater off. Using a thermostat reduces energy consumption, saves on running costs and helps to create the most comfortable environment in the room. We have a choice of different thermostats available as optional accessories. The TS10 Plug In Thermostat plugs into a mains power socket and then a SmartLine panel plugs into the thermostat. It is a straightforward thermostat that allows you to set the desired temperature, timer, and automated programmes. We also have the BT710 Wireless Thermostat available with a BT003 Plug In Receiver. 2 x AAA batteries power the wireless thermostat, and it can be used free-standing or mounted on a wall. It features a digital display and allows you to input a temperature, set a timer and set up a weekly programme. It has a range of 35m, and it can be connected to up to 9 receivers to control multiple heaters within a space. The receiver plugs into a power socket and the SmartLine heater plugs into the receiver. The receiver controls the heater based on the data transmitted by the wireless thermostat. You can add a thermostat to your online order above by ticking the thermostat that you require. You can also order by contacting our sales team via online live chat or telephone.

Please allow 6 working days for delivery.

Surface: Powder Coated Sheet Steel
Colour: White
Rear panel: Untreated Aluminum
Field of application: Direct Heating
Surface temperature: Approx. 90°C - 110°C
Voltage: 230 Volt, 50/60 Hz
Protection: IP 45, Protection Class 1
Temperature protection: 1-2 sensors, dependent on heater dimension
Power supply: Type CEE 7/7 tilted, 8 mm flat; cable length: 1.9 m

Model Specifications:
Heat4All SmartLine 175: Dimensions 495 x 350 x 16mm. Nominal Output 170w. Weight 2.3kg. Heatable Area 2-5m².
Heat4All SmartLine 320: Dimensions 595 x 595 x 16mm. Nominal Output 320w. Weight 4.3kg. Heatable Area 4-8m².
Heat4All SmartLine 520: Dimensions 950 x 615 x 16mm. Nominal Output 520w. Weight 6.7kg. Heatable Area 8-12m².
Heat4All SmartLine 700: Dimensions 1100 x 650 x 16mm. Nominal Output 700w. Weight 8.2kg. Heatable Area 11-19m².
Heat4All SmartLine 1000: Dimensions 1240 x 815 x 16mm. Nominal Output 1000w. Weight 11.2kg. Heatable Output 16-24m².

Low Cost: Heat4All SmartLine panels are infrared heaters that are low-cost, highly efficient and safe.

Various Mount Options: These panels enable you to create a lovely room climate without taking up space, as they can be mounted onto a wall or ceiling.

Steel & Alu Design: SmartLine panels have specially designed frames and mounting studs to ensure excellent stability and robustness. The front panel is coated steel with high IR radiation ratio and high UV persistence while the rear panel has a metallic surface and a lower IR-emissivity.

Heating Elements: Internally, Heat4All SmartLine panel heaters feature high-quality heating elements with constantan heating conductor and an air buffer insulation with an IR reflector. These components ensure heating efficiency, reduced energy consumption and reduced running costs.

Size & Heating Options: These infrared panel heaters are available in a range of different sizes, each with different heating capacities, so they can be used for heating a range of spaces of different sizes.

Easy To Install: These panel heaters come with a 1.9m power cable and 230v plug, as well as an easy to use, sturdy, adjustable mounting kit and mounting manual. They do not need to be wired into the mains by a professional electrician.

Thermostat Options Available: Heat4All SmartLine panel heaters can be used with an optional thermostat for full control of the heating within the room. We have a choice of different thermostats available as optional accessories.
