Baxi HP40 5kW Monobloc Air Source Heat Pump 5kW

Baxi HP40 5kW Monobloc Air Source Heat Pump

The Baxi HP40 5kW Monobloc Air Source Heat Pump is a low-carbon alternative to supplying homes with hot water and heating. Replacing fossil-fuel boilers, they work by drawing out the free heat from the air outside and transferring it to radiators and hot water systems. This not only lowers the money spent on household bills, but also reduces your carbon footprint compared to an old gas boiler.

This 5kW model is the same size as the 4kW version, but features extra heating power without the need for any additional outdoor space for installation. We recommend you have a MCS-certified fitter carry out a heat-loss calculation to BS EN 12831 standards before sizing your unit.

Features & Benefits: Baxi HP40 5kW

• Twin Rotary Compressor: Adjusts power based on the temperature outside instead of waiting for your house to get cold. This prevents the wasteful on/off cycling of traditional gas boilers.

• A+++ Energy Rating: The HP40 5kW can deliver up to 4.77 SCOP at 35°C flow. This gives homeowners 5kW of heat for every 1kW of electricity used to reduce winter running costs.

• Monobloc Design: With all of its internal components sealed inside one outdoor unit removes the need for complicated refrigerant installation. It also gets rid of technical on-site F-Gas handling.

• Works in Low Temperatures: Continuing to work in outdoor temperatures all the way down to -25°C, these units are truly dependable when the cold weather hits.

• ADEY Protection: The HP40 comes with an ADEY magnetic filter that captures debris within the system, shielding internal pumps from early wear.

Baxi Cylinder Compatibility

To get the best results when heating water, we recommend pairing the 5kW HP40 with Baxi’s range of hot water cylinders that boost heating efficiency during the winter. Depending on how much hot water you generally use, Baxi recommends a hot water tank between 100 and 250 litres for this model.

Buy the Baxi HP40 5kW R32 Online

Available to purchase today from National Heater Shops. We offer a Price Match Promise, rapid UK delivery and technical support from our HVAC team.

• Model: HP40-5-1PHMB
• Heating Output: 5kW
• Power Supply: 220–240V, 50Hz, Single-Phase
• Minimum Circuit Amps (MCA): 14A
• Maximum Fuse Rating: 25A
• Compressor Rated Load Amps: 13.5A
• Refrigerant: R32
• Refrigerant Charge: 1.40kg
• CO₂ Equivalent: 0.95 tonnes
• Heating Water Temperature Range: 12–65°C
• Cooling Water Temperature Range: 5–25°C
• Heating Ambient Operating Range: -25–35°C
• Cooling Ambient Operating Range: -5–43°C
• DHW Ambient Operating Range: -25–43°C
• Water Connection: G1" BSP
• Expansion Vessel Capacity: 8L
• Maximum Expansion Vessel Pressure: 8bar
• Water Circuit Pressure Relief Valve: 3bar
• Pump Type: Water-Cooled, Variable Speed
• Dimensions (H × W × D): 792 × 1295 × 429mm
• Net Weight: 98kg
• Gross Weight: 121kg
• Warranty: 2 Years
