Arcotherm Package Jumbo 85M Indirect Oil Fired Space Heater - 240v 79kW

Arcotherm Jumbo 85M Indirect Oil Fired Heater Package

High-Performance Indirect Heater for Large Commercial & Industrial Areas

The Arcotherm Jumbo 85M provides reliable, high-capacity heating for large enclosed or semi-open spaces including warehouses, factories, construction sites, marquees and agricultural buildings. It delivers 79 kW of clean, fume-free heat with 7,200 m³/h airflow for effective temperature control in demanding environments.

Complete Package Solution

Supplied as a full package with the components needed for quick installation and operation. The kit contains the Arcotherm Jumbo 85M indirect oil fired heater, Ecoflam diesel burner, thermostat with 10 m lead, ducting adaptor, flue pipe, and rain cowl. Each component is designed to work together for efficient performance and straightforward site setup.

Robust Construction & Efficient Performance

The Jumbo 85M features a high-efficiency 7-blade fan and a redesigned combustion chamber to optimise airflow and fuel usage. Dual-voltage (230 V / 110 V) capability supports a range of site power supplies. A heavy-duty steel frame, large transport wheels and corrosion-resistant panels make it suitable for industrial use and easy movement between locations.

Clean, Safe Heating

As an indirect heater, the Jumbo 85M supplies only clean, fume-free warm air to the target area while exhaust gases are expelled through the flue to maintain air quality. Thermostatic control and high combustion efficiency provide safe, economical operation for extended site use.

Optional Accessories & Upgrades

Optional configurations include one-way 450 mm and two-way 400 mm outlets, Riello and Ecoflam diesel burners, LPG Riello burner with gas train, Natural Gas Riello burner with gas train, and a Dual Voltage Kit.

Buy the Arcotherm Jumbo 85M Indirect Oil Fired Heater Package from National Heater Shops — trusted Arcotherm quality, expert support and fast UK delivery.

JMB85ECOKIT

Heater Dimensions: 1648mm x 770mm x 1133mm
Packaged Heater Dimensions: 1600mm x 680mm x 1135mm
Product Weight: 172kg
Packaged Weight: 192kg
Heating Capacity: 79kW
Heat Efficiency: 92.7%
Air Flow: 7,200m³/h
Air Temperature: 47℃
Fuel Consumption: 6.77l/hr
Electrical Power: 700W

100% Clean Hot Air: The heater blows out 100% clean, fume-free warm air from its warm air outlet. This makes it ideal for heating enclosed areas safely, such as marquees and tents, workshops, warehouses, areas on construction sites and much more.

Portable Design: Large wheels and a handle make the heater very portable. It is easy to transport, position and re-position when required on site. Lifting eyes on top of the unit allow it to be lifted on and off transport.

Flue Gas Exhaust: Combustion by-products are exhausted out of the top of the heater. Sections of flue pipe are available separately, allowing you to safely vent exhaust fumes away from the space.

High Quality Components: High-performance 7-blade fan assembly and redesigned combustion chamber, Tiger Loop, 450mm One Way Adaptor, Jumbo 85 Ecoflam Diesel Burner, 300mm Crush Proof Fuel Hose, 6000 Series ISO Male Tip Pro and BSPP Male x BSPP Male adapter.

Thermostat Connectivity: An optional heavy-duty thermostat can be connected to this heater, allowing you to set a required temperature within the space. The thermostat will switch the heater on and off as required to maintain the set temperature. This saves fuel and adds extra convenience.

Tigerloop Included: This heater features no internal fuel tank. It is designed to be connected to an external fuel tank of your choice. The tigerloop removes any air from the fuel as it enters the heater.

Ducting Connection: Sections of ducting can be attached to this heater, to direct the clean warm air into the space that you need to heat.

Tough & Robust: Built to perform in challenging areas, including construction sites, workshops, warehouses, agriculture, events and more.
